Fast SiC semiconductor lnc.即思創(chuàng)意股份有限公司專注于sic功率組件之無晶圓廠設計公司，主要提供有650V~1700V之SiC MOSFET與SiC二極管，目前唯一將SIC MOSFET設計可符合常規(guī)之12v硅基閘極驅動器使用?，F(xiàn)時碳化硅主要應用領域將會于高功率電源市場以及極端環(huán)境下的各式應用中。| Product No. | Drain-source?Voltage[V] | Drain-source?On-state?Resistance(Typ.)?[mΩ] | Package | PDF下載 |
|---|---|---|---|---|
| FF06030Q | 650 | 30 | TO-247-4L | 暫無 |
| FF06100G | 650 | 100 | DFN8x8 | 暫無 |
| FL06100C | 650 | 100 | TO-220-3L | 暫無 |
| FF06100D | 650 | 100 | TO-220FP | 暫無 |
| FL06100D | 650 | 100 | TO-220FP | 暫無 |
| FF06100F | 650 | 100 | TOLL | 暫無 |
| FL06150A | 650 | 150 | DPAK(MSL 1) | 暫無 |
| FF06320A | 650 | 320 | DPAK(MSL 1)? | 暫無 |
| FL06320A | 650 | 320 | DPAK(MSL 1) | 暫無 |
| FF06320B | 650 | 320 | PQFN5x6(MSL 1) | 暫無 |
| FL06320B | 650 | 320 | PQFN5x6(MSL 1) | 暫無 |
| FL06320G | 650 | 320 | DFN8x8 | 暫無 |
| FF061K4 | 650 | 1400 | DPAK(MSL 1) | 暫無 |
| FF12040F | 1200 | 40 | TO-247-3L | 暫無 |
| FF12040Q | 1200 | 40 | TO-247-4L | 暫無 |
| FL12190A | 1200 | 190 | DPAK(MSL 1) | 暫無 |
| FL12190G | 1200 | 190 | DFN8x8 | 暫無 |
| FL12190I | 1200 | 190 | SOIC-8 | 暫無 |
| FF17900E | 1700 | 900 | TO-247-3L | 暫無 |
| FF17900Q | 1700 | 900 | TO-247-4L | 暫無 |
